Product introduction

MTL SD16R is a surge protector produced by MTL Instruments, belonging to the SD series. The following is a detailed introduction: - **Functions**: It adopts a multi-stage hybrid protection circuit, with a maximum surge

MTL SD16R is MTL This surge protector, part of the SD series, is manufactured by Instruments. The following is a detailed introduction: - **Features**: It utilizes a multi-stage hybrid protection circuit with a maximum surge current of 20kA (8/20μs), automatic recovery, and requires no maintenance. Its high bandwidth and low resistance effectively protect electronic equipment and systems from surges on signal and I/O cables. - **Protection Circuit**: It provides comprehensive protection for two-wire or three-wire circuits, including RTDs, THCs, and 4-20mA circuits in control systems. - **Operating Voltage**: The nominal operating voltage is 16V, with a maximum continuous operating voltage of 17V and a nominal current of 400mA. - **Mounting Method**: It mounts securely to a T-section 35x7.5 or 35x15mm DIN rail. It clips securely to the rail with a simple manual operation and automatically establishes a reliable ground connection. - **Applications**: ATEX-certified, this intrinsically safe surge protector is suitable for use in hazardous locations. Its high bandwidth makes it ideal for protecting high-speed data communication systems such as RS232, RS422, and RS485, as well as buses. - **Product Dimensions**: Its ultra-thin, modular design and compact structure save cabinet space and achieve high packaging density. - **Other Features**: An optional "loop disconnect" function allows customers to simply disconnect the SPD during installation, commissioning, and maintenance without disconnecting the circuit breaker; simply remove the fuse.

MTL Safety Barrier/Eaton Safety Barrier SD16R Surge Protector

MTL safety barrier/Eaton safety barrier SD16R Surge Protectors

We have the discontinued spare parts you need right here.
